- New Aerodynamic 10 blade billet compressor wheel flow more air over the stock cast or Gen1 11 blade billet wheel
- New Aerodynamic 9 blade turbine wheel, less weight, lower inertia, and higher flowability
- Genuine structure and rebuildable dual ceramic ball bearing system
- Larger 0.72A/R compressor cover with Anti-Surge 4″ inlet
- Billet actuator with black anodized coating
- 3 Layer Stainless Steel 5 Bolt Gasket
- Compressor Wheel: 67.3*84.4mm(extended tip diameter: 87.3mm)
- Turbine Wheel: 68*62.3mm
- Compressor Inlet: 4″ Hose
- Compressor Outlet: 2.5″ Hose
- Turbine Inlet: T3 Open
- Turbine Outlet: 5 Bolt
- Turbine housing internal wastegate hole: 33mm
- Water Ports: -6AN
- Oil Feed: -4AN to the Oil Restrictor
- Oil Drain: Std T3 Oil Drain Flange
- Actuator working pressure: 15psi
- Add additional 6.5PSI spring, Please note this is not fitted. If you require this please note at checkout
